PLX51-PBM Technical Specifications
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 187 of 196
9.2 Electrical
Table 9.1 - Electrical specification
Specification
Rating
Power requirements
Input: 10 – 36V DC
Power consumption
Maximum: 85mA @ 24V => 2.04W
Connector
3-way terminal
Conductors
24 – 18 AWG
Enclosure rating
IP20, NEMA/UL Open Type
Temperature
-20 – 70 °C
Earth connection
Yes, terminal based
Emissions
IEC61000-6-4
ESD Immunity
EN 61000-4-2
Radiated RF Immunity
IEC 61000-4-3
EFT/B Immunity
EFT: IEC 61000-4-4
Surge Immunity
Surge: IEC 61000-4-5
Conducted RF Immunity
IEC 61000-4-6
9.3 Ethernet
Table 9.2 - Ethernet specification
Specification
Rating
Connector
RJ45
Conductors
CAT5 STP/UTP
ARP connections
Max 40
TCP connections
Max 40
CIP connections
Max 10
Communication rate
10/100Mbps
Duplex mode
Full/Half
Auto-MDIX support
Yes
Embedded switch
Yes, 2 x Ethernet ports
