ProSoft Technology PLX51-PBM User Manual

PLX51-PBM Appendix
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 193 of 196
11 Appendix
11.1 DPV1 Response Status (Master Only)
Table 11.1 – DP Status Response codes
DP Status
Description
00h
Successful
05h
FDL error (see extended error code)
06h
DPV1 Error (see extended error code)
07h
Another command is already in progress for this slave / class 2
connection.
11h
Online state expected
13h
Invalid slave response
17h
Timeout passed
11.2 DPV1 Extended Status Codes (Master Only) – FDL Error
Table 11.2 – DP Extended Status Response codes (FDL Error)
DP Status – Byte 0
Description
0h
OK
1h
User error, SAP locked
2h
No resource for sending data, tried to send to SAP that was not
configured
3h
No service available (SAP does not exist)
4h
Access point blocked
NOTE: With an FDL Error, Extended Status bytes 2 and 3 will be zero.
11.3 DPV1 Extended Status Codes (Master Only) – DPV1 Error
11.3.1 DPV1 Read/Write Error
DPV1 Extended Status - Byte 1
Table 11.3 – DP Extended Status Response codes (DPV1 Error) – Byte 1
Value
Description
0 to 127
Reserved
128
DPV1
129 to 253
Reserved
254
PROFIBUS FMS
255
N/A
