ProSoft Technology PLX51-PBM User Manual

PLX51-PBM Diagnostics
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 157 of 196
8.2 Module Status Monitoring
The PLX51-PBM provides a range of statistics which can assist with module
operation, maintenance, and fault finding. The statistics can be accessed in full by
the PLX50 Configuration Utility or using the web server in the module.
To view the module’s status in the PLX50 Configuration Utility environment, the
PLX51-PBM must be online. If the module is not already Online (following a recent
configuration download), then right-click on the module and select the Go Online
option.
Figure 8.2 - Selecting to Go Online
The Online mode is indicated by the green circle behind the module in the Project
Explorer tree.
