ProSoft Technology PLX51-PBM User Manual

PLX51-PBM Setup
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 60 of 196
3.9.1 General
The General configuration is shown in the figure below. The Device General
configuration window is opened by either double clicking on the slave device in the
tree or right-clicking the slave device and selecting Configuration.
Figure 3.69 – Device General configuration parameters
When the module is emulating the legacy device, the PLX51-PBM General
configuration parameters will appear as follows:
Figure 3.70 – Device General configuration parameters (legacy device)
The General configuration consists of the following parameters:
Table 3.16 –Device General configuration parameters
Parameter
Description
Instance Name
The device instance name which will be used to create the Tag
names and UDTs in Logix.
