ProSoft Technology PLX51-PBM User Manual

PLX51-PBM Appendix
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 195 of 196
11.3.2 DPV1 Abort
DPV1 Extended Status - Byte 1 - Subnet
Table 11.5 – DP Extended Status Response codes (DPV1 Error) – Byte 1 – Subnet
Value
Description
0
No Subnet
1
Local Subnet
2
Remote Subnet
3 to 255
Reserved
DPV1 Extended Status - Byte 2 – Instance/Reason
Table 11.6 – DP Extended Status Response codes (DPV1 Error) – Byte 2 – Instance/Reason
Value
Description
Bit 6 to 7
Reserved
Bit 4 to 5
00 – FDL
01 – MSAC_C2
10 – User
11 – Reserved
Bit 0 to 3
See EN 50170 Part 2
