1 – The PLX51-PBM is in Slave Mode.
0 – The PLX51-PBM is not in Slave Mode.
ConfigCRC
The signature of the configuration currently executing on the
module.
DeviceListList
Indicates the nodes that are online on the local PROFIBUS
network. Each bit represents a node. When the specific bit is set ‘1’
then the device is online and when the bit is off ‘0’ the device is not
on the PROFIBUS network.
Bit 0 – Node 0 Online
Bit 1 – Node 1 Online
Bit 126 – Node 126 Online
DeviceDataExchangeActive
Indicates the nodes that are online and exchanging DPV0 data on
the local PROFIBUS network. Each bit represents a node. When
the specific bit is set ‘1’ then the device is online and exchanging
data and when the bit is off ‘0’ the device is not exchanging data on
the PROFIBUS network.
Bit 0 – Node 0 Exchanging DPV0 Data
Bit 1 – Node 1 Exchanging DPV0 Data
Bit 126 – Node 126 Exchanging DPV0 Data
DeviceAlarmPendingFlags
Indicates the nodes that have an alarm pending on the local
PROFIBUS network. Each bit represents a node. When the
specific bit is set ‘1’ then the device has an alarm pending that
must be unloaded and when the bit is off ‘0’ the device does not
have an alarm pending.
Bit 0 – Node 0 has an alarm pending
Bit 1 – Node 1 has an alarm pending
Bit 126 – Node 126 has an alarm pending
DeviceDiagnosticPendingFlags
Indicates the nodes that have diagnostics pending on the local
PROFIBUS network. Each bit represents a node. When the
specific bit is set ‘1’ then the device has diagnostics pending that
must be unloaded and when the bit is off ‘0’ the device does not
have any diagnostics pending.
Bit 0 – Node 0 has diagnostics pending
Bit 1 – Node 1 has diagnostics pending
……….
Bit 126 – Node 126 has diagnostics pending
