PSI PP4050 XP - Replacing the Ozone Filter

6
3
4
5
Maintenance
5-11
5.2.3 Replacing the Ozone Filter
$ Press first . OFFLINE will be displayed.
$ Open the front (3) and rear (4) cover.
$ Press the green lever to open the top cover (5), illustrated before.
$ Loosen the screw (2) and remove the Transfer Charge Unit (1), illustrated
before.
Note:
The Transfer Charge Unit is a delicate equipment which needs to be
handled with care!
$ Remove the Ozone Filter (6) by using the small tab at the side and insert the
new Ozone Filter, illustrated below.
$ Insert the Transfer Charge Unit by using the iron band guides at both sides
and fix it with the screw (2).
$ Close the top (5), rear (4) and front cover (3).
