PSI PP4050 XP - Installation of the Consumables; Loading the Developer Unit

7
8
Installing the Printer and the intelligent Paper Stacker
1-12
Installation of the Consumables
1.5.1 Loading the Developer Unit
$
Lift the lever (26) upwards to unlock the Developer Unit.
$
Pull the Developer Unit (6) about
- out of the housing and grasp the grip (7)
with one hand and remove it.
$ Remove the plastic bag from the clutch on the rear side.
$ Remove plastic and paper safety strips (8) from the area of the toner output
of the Developer Unit (6).
Note:
Don´t destroy the small plastic lip above the toner output of the
Developer Unit (6).
$ Insert the Developer Unit (6) (step 2.) and secure it by pressing down the
lever (26).
