PSI PP4050 XP - Image Width; Source; Destination

Explanation of Individual Menu Items
This menu item is only displayed if PAPER size
CUSTOM
is selected.
1)
4-9
$
IMAGE WIDTH
1)
The print image is always centered on a page - not at the left or right margin.
The width of the print image can be selected from min. 0.5 inch (12.7 mm)
up to max. 17.00 (431.8 mm) in steps of 0.05 inch (1.27 mm):
0.50; 0.55; 0.60; 0.65; .......
17.00
;
Note:
If ORIENTATION = LANDSCAPE is selected the image width now
corresponds to the page height.
$
SOURCE
The printer offers two choices for fanfold paper input:
-
LOWER
(default)
-
UPPER
Note:
Please refer to chapter
7 Technical Data
for media specifications.
$
DESTINATION
It is possible to choose between
BOTTOM
and
BOTTOM CUT
(to leave the
printer at the paper exit on the right side).
If
BOTTOM
(default) is selected fanfold paper leaves the printer at the paper
exit (right side). The cutter is not activated by default. If print jobs shall be
separated the cutter must be activated via ESC sequences from the host
system.
BOTTOM CUT
means that page by page will be cut.
The position where the paper is cut is determined by the parameter Paper
Length.
Note:
If, for some reason, it is not desired to cut exactly on the perforation it
is very important to
cut below the perforation
.
If the paper is cut above the perforation the remaining paper can
easily bend and cause a paper jam. Do not cut through a label as the
blade would get dirty by the glue. See also
CUT SHIFT
to adjust the
cut position.
