Appendix A Programming Guide
A-39
$
Example for EAN 13 SC2
type =EAN 13 SC2: ESC * z 1 2 2 V
orient. = 180° ESC & a 1 8 0 P
text = OCR-B below ESC * z 2 Q
data = 4 1 2 3 4 5 6 7 8 9 0 1 8 ESC * z 1 3 Z 4 1 2 3 4 5 6 7 8 9 0 1 8
The HEXDUMP datastream for this example is:
1B 2A 7A 31 32 32 56 1B 26 61 31 38 30 50 1B 2A
7A 32 51 1B 2A 7A 31 33 5A 34 31 32 33 34 35 36
37 38 39 30 31 38
Print sample:
$
Example for Codabar
type = Codabar ESC * z 1 8 0 V
ratio = 3.0 ESC * z 3 . 0 O
text = OCR-B below ESC * z 2 Q
data = a 0 1 2 3 4 5 6 7 8 9 t ESC * z 1 2 Z a 0 1 2 3 4 5 6 7 8 9 t
The HEXDUMP datastream for this example is:
1B 2A 7A 31 38 30 56 1B 2A 7A 33 2E 30 4F 1B 2A
7A 32 51 1B 2A 7A 31 32 5A 61 30 31 32 33 34 35
36 37 38 39 74
Print sample:
