Appendix A Programming Guide
A-24
A-3.7
Graphic Commands
GRAPHIC
Description
COMMANDS
ESC * v # N
Source Transparency Mode
ESC * v # O
Pattern Transparency Mode
ESC * c # G
Area Fill ID
ESC * v # T
Select Current Pattern
ESC * c # W [data]
Define User Defined Pattern
ESC * p # R
Set Pattern Reference Point
ESC * c # Q
User Defined Pattern Control
ESC * t # R
Raster Graphic Resolution
ESC * r # F
Raster Graphic Presentation
ESC * r # T
Raster Graphic Heigth
ESC * r # S
Raster Graphic Width
ESC * r # A
Start Raster Graphics
ESC * b # Y
Raster Graphic Y Offset
ESC * b # M
Raster Graphic Compression Mode
ESC * b # W [data]
Transfer Raster Graphic Data
ESC * B
or ESC * C
End of Raster Graphic
ESC * c # A
Horizontal Rectangle Size, PCL Units
ESC * c # H
Horizontal Rectangle Size, Decipoint
ESC * c # B
Vertical Rectangle Size, PCL Units
ESC * c # V
Vertical Rectangle Size, Decipoints
ESC * c # G
Pattern ID for Area Fill
ESC * c # P
Fill Rectangle Area
ESC * c # X
HPGL Horizontal Picture Frame Size
ESC * c # Y
HPGL Vertical Picture Frame Size
ESC * c 0 T
HPGL Picture Frame Anchor Point
ESC * c # K
HPGL Horizontal Plot Size
ESC * c # L
HPGL Vertical Plot Size
ESC % # B
Enter HPGL Mode
ESC % # A
Return from HPGL to PCL Mode
Note:
For detailled informations see HP PCL 5 Technical Reference Manual.
