Configuring the Printer
3-6
--- Configuration (Default) ---> Profile 1 ---
PAPER MENU PCL MENU *) GENERAL MENU
PAPER = CUSTOM FONT NUMBER = 0 EMULATION = PCL
PAPER LENGTH = 12 INCH PITCH = 10.00 **) AUTO FORM FEED = OFF
TWO-UP-MODE = OFF SYMBOL SET = ROMAN-8 AUTOMATIC CUT = OFF
LENGTH FACTOR = 1 LINE SPACING = 6 LINES / INCH JOB SEPARATION = OFF
STCK. PAPER WIDTH = 18.00 INCH TOP MARGIN = 0 LINES TRACTOR CHANGE CUT = ON
IMAGE WIDTH = 17.00 INCH LEFT MARGIN = 0 COLUMNS REPRINT LAST PAGE = OFF
SOURCE = LOWER RIGHT MARGIN = MAXIMUM
DESTINATION = BOTTOM TEXT LENGTH = 72 LINES
ORIENTATION = PORTRAIT PERF. SKIP = OFF
LANDSCAPE MODE = REVERSE $$ COMMANDS = OFF
ORIENT. MODE = FIXED
PAPER EXTENDED = NO
PAPER SELECTION = ONLY PJL
PAPER PATH SELECT. = RECOGNIZE
FUSER TEMP. = MIDDLE
TONER DENSITY = MIDDLE
VER SHIFT = 0/100 INCH
HOR SHIFT = 0/100 INCH
CUT SHIFT = 0/100 INCH
REGISTRATION CURVE = 1
CONFIG. MENU
POWER SAVE = 15 MIN
KEEP TEMP. HIGH = 1,0 MIN
ALARM BELL = ON
LANGUAGE = ENGLISH
MENU ACCESS = ALL
HOST CHANNEL = PARALLEL ONLY
TRACTOR POOL = ON
RECALL FACTORY = NO
RESET DEVELOP. INFO = NO
RESET OPC INFO = NO
RESET FUSER INFO = NO
3.3 Printout of the 50 Profiles
To printout the contents of all 50 Profiles use the same sequence as described
in paragraph 3.2.1 How to Start the SELF TEST up to point 6.
After selecting CONFIG. PRINT, the printer starts to print all 50 Profiles.
Sample of PROFILE 1
*) Depending on setting of EMULATION in the GENERAL MENU (see
TEST PRINT) either PCL MENU or HEXDUMP MENU is indicated.
**) This value is depending on selected FONT NUMBER;
for FONT NUMBER 0, 39 - 44 = PITCH and
for FONT NUMBER 1 - 38 = POINT SIZE
See Paragraph 3.4 Menu Structure for the different entry points and Chapter
4 Explanation of individual Menu Items !
