8–Configuring FCoE in a Linux Environmen
t
Boot-from-SAN
8-34
FE0254
601-00 A
Figure 8-13. Multipath T
opology
Converged
Networking
Switch 1
Storage Array
Server
Controller A
CNA Port 1
LUN 1 (Primary Boot Device)
LUN 3 (Alternate Boot Device)
LUN 2 (Alternate Boot Device)
LUN 4 (Alternate Boot Device)
CNA Port 2
Converged
Networking
Switch 2
Controller B
