A Adapter Port LEDs
Figure A-1 shows the QLogic 8100 Series Adapter Storage Traffic and
Link/Ethernet Traffic port LEDs. Each port has its own LEDs.
 The Storage Traffic LED indicates the state of data traffic exchanged with
the SAN.
 The Link/Ethernet Traffic LED indicates the state of data traffic exchanged
with the LAN.
Observe the LED states, and refer to Table A-1 for indications of firmware or
hardware conditions.
Figure A-1. QLogic 8100 Series Adapter LEDs
Link/Ethernet Traffic LED
Storage Traffic
