Specifications Product Description
4 CubiScan 110
Physical
Measuring Surface: 32 x 24 in (81 x 60 cm)
Total Footprint Required: 43 x 34 in (109 x 86 cm)
Height: 47 in (119 cm)
Shipping Weight: 256 lb (116 kg)
Net Weight: 78 lb (35 kg)
Shipping Dimensions: 52 x 50 x 18 in
Outputs
One (1) EIA RS-232-C serial communications port
See Appendix A for communications protocol.
10-BaseT Ethernet TCP/IP port
See Appendix A for communications protocol and setup parame-
ters. Qbit™, QbitTCP software can be used to configure (through
the RS-232-C port) the CubiScan 110 for TCP/IP communication.
Contact Quantronix for information.
Load Cell
The load cell is made of forged, machined and anodized aluminum,
environmentally sealed up to IP65 levels Dual bridge 350 Ohm
strain gage. The standard net capacity is 100 lb (45 kg)
