Calibrating Using the Control Panel Calibration
38 CubiScan 110
4. Use the tip of a pen or pencil or similar device to move switch 6
on the DIP switch back to the “open” position.
5. Slide the cover back into place over the controller box, and reat-
tach the screws.
6. Place the controller box back in the base, and reattach the four
Allen head screws on the corners of the controller box mounting
plate using the 2.5 mm Allen wrench.
7. Tip the front of the CubiScan up enough to reach under and plug
the RS-232 serial cable back into the connector on the right side
of the controller box, and tighten the thumb screws.
8. Plug the power cord back into the power strip, and turn it on.
