QubicaAMF XLi EDGE Pinspotter

Section 4-6 Page 4.6-16 Rev. Date: 10/2016

4.6.3.6 PROBLEM: Sweep arm hits frame of machine at zero. position.

Figure 4.6-15

Adjust sweep drive tie

rod in accordance with

Section 4.

START

Clearance between box

beam & stabilizer link less

than 0.5 inches?

Interference with side

frame?

Shim sweep main pivot

shaft support block to

obtain clearance.

Sweep linkage binding?

Find and repair bind.

YES
