QubicaAMF XLi EDGE Series User Manual

Troubleshooting
400-088-120-02 Page 4.6-17 Rev. Date: 10/2016
Section 4.6
4.6.3.7 PROBLEM: 1
st
ball – table comes down and picks up standing
pins, but does not respot them. Sweep remains at guard
position.
Figure 4.6-16
START
Off spot switch
adjusting screw
turned out too far?
Off-Spot switch
shorted?
Off-Spot switch wiring
shorted?
Defective chassis?
Bind in table drive
mechanisms?
Check with gauge #088-001-217.
Adjust screw according to gauge.
Check with continuity tester.
Replace switch if defective.
Check with continuity tester.
Repair wiring if defective.
Replace chassis.
Repair table drive
mechanisms.
NO
NO
NO
NO
YES
YES
YES
YES
YES
Bind in the Off-Spot
switch lever?
Repair Bind.
NO
YES
