RADWIN2000CPlusUserManual Release3.5.70 9‐8
ObtainingReports Chapter9
Figure9‐3:Downlink‐PerformanceMonitoringreport‐Validdata
Theon‐screenreportmaybescrolledverticallyandhorizontally.Themeaningofthecolumn
headingsisshowninthefollowingtable:
Table9‐2:HBSPerformanceMonitoringFields
ColumnHeading
Abbreviation
Meaning
Description
Integrity Validdataflag
Greentickforcurrentandvalid;Redcrossfor
invalidateddata(Seeexamplebelow).Notethatthe
PerformanceMonitoringdataisnotvalidifnotallthe
valueswerestored(e.g.,duetoclockchangeswithin
theintervalorpowerupreset)
Date&Time Timestamp
Dataarerecordedevery15minutes;thelast30days
ofrecordingsaremaintained.Roll‐overisatmidnight.
UAS
Unavailable
Seconds
Secondsinwhichtheinterfacewasoutofservice.
ES Erroredseconds
Thenumberofsecondsinwhichtherewasatleast
oneerrorblock.
SES
SevereErrored
Seconds
Thenumberofsecondsinwhichtheservicequality
waslowasdeterminedbytheBBERthreshold.
BBE
Background
BlockError
Thenumberoferroredblocksinaninterval.
RxMBytes
Received
Mbytes
ThenumberofMegaby tesreceivedatthespecified
portwithintheinterval
TxMBytes
Transmitted
Mbytes
ThenumberofMegaby testransmittedatthe
specifiedportwithintheinterval.
AboveTraffic
Thresh
Thresholdsetin
Figure 9‐2
Secondscountwhenactualtrafficex ceededthe
threshold
ActiveSeconds
ThenumberofsecondsthattheconfiguredEthernet
serviceisactive
