RADWIN2000CPlusUserManual Release3.5.70 4‐9
Toolsrequiredforinstallation Chapter4
Figure4‐13:UsinganEthernetrepeaterwithlightningprotectors
Toolsrequiredforinstallation
ThefollowingisalistoftheequipmentandmaterialsrequiredtoinstallRADWIN2000CPlus
hardware.
ToolsandMaterials
• CrimpingtoolforRJ‐45(ifthe ODU‐PoEcableiswithoutconnectors)
• Spanner/wrench13mm(½”)
• Drill(forwallmountingonly)
• Cableties
• Sealingmaterial
• WaterproofingtapesuchasScotch23Tape¾”wide,from3MtoensureIP‐67compliant
protectionagainstwateranddust
Note
TheEthernetrepeatercannotbeusedwithGbEPoE‐ODUcables.
