Radwin 2000 C PLUS User Manual

RADWIN2000CPlusUserManual Release3.5.70 4‐1
Chapter4:
HardwareInstallation
Overview
Thischaptercoverstherequirementsandproceduresforthehardwareinstallationand
alignmentofaRADWIN2000CPlussectorinaccordancewithpriorplanning.(SeeChapter3.)
Itisintendedtoassistqualifiedfieldtechnicians.
Thischaptercoversthefollowingtopics:
• Unpackingandcheckingsuppliedequipment:
• ODUs
• PoEdevices
• IDU‐Haggregationunit
• Antennas
• Accessories
• Toolsrequiredforinstallation
• Safetypractices
• MountinganODU
• ConnectinganODU
• GroundingandlightningprotectionforanODU
Warning
OutdoorunitsandantennasshouldbeinstalledONLYbyqualifiedfield
technicianswhoarefamiliarwithlocalbuildingandsafetycodesand,
whereverapplicable,arelicensedbytheappropriategovernment
regulatoryauthorities.Failuretodosomayexposetheenduserorthe
serviceprovidertolegalandfinancialliabilities.RADWIN
anditsresellersor
distributorsarenotliableforinjury,damageorviolationofregulations
associatedwiththeinstallationofoutdoorunitsorantennas.
Note
ThematerialinthischapterislargelygenerictoallRADWINradioproducts
unlessstatedotherwise.ODUmaybeanHBSoranytypeofHSU.

Radwin 2000 C PLUS Specifications

General

Brand	Radwin
Model	2000 C PLUS
Category	Radio
Language	English
