RADWIN2000CPlusUserManual Release3.5.70 6‐2
SettingtheconnectedODUasMasterODU Chapter6
• UplinkanddownlinkMaximumInformationRate(MIR)inMbps
• VLANparameters
• Qualityofserviceparameters.
Inwhatfollows,weassumethat youareloggedontooneoftheODUsonIPaddressasshown
inthepreviouschapter.Hereistheopeningsituation:
Figure6‐1:Mainwindowpriortolinkconfiguration
SettingtheconnectedODUasMasterODU
OpentheConfigure|Operationstab:
Note
TheODUsassuppliedcanbeusedasHSUsinaPtMPsectororODUsinaPtP
linksuchaswearedescribinghere.Untilthelinkisestablished,youwillsee
referencesintheRADWINManagertounfamiliartermssuchas“Nomadic”
and“Mobility”.AssoonasanHSUisconfiguredforPtPmostofthemwillno
longerbeseen.
