RADWIN2000CPlusUserManual Release3.5.70 6‐19
LinkStatusLight Chapter6
LinkStatusLight
ThemeaningofLinkStatusLightisasfollows:
BottomStatusLine
Table6‐1:LinkStatuslightcolorcodes
Color Description
Green SlaveODUregistered,insync
Red SlaveODUregistered,nosync
Purple Authenticationerror
Brown SoftwareUpgraderequired
Gray SlaveODUunregistered
Table6‐2:StatusLineItems
Item Description
ConnectionState AvailableorUnreachable,dependingonsyncstatus
ConnectionMode Network,OvertheAirorLocal
IPAddress ConnectedIPaddressor255.255.255.255forlocalconnection
Familyname RADWIN5000
Encryption
AES128isonbydefault.AES256requiresalicensekey .SeeConfiguring
AES256EncryptionSupportbelow.
AESIndicatorsforalink
AESLevel
Supported
LicensedforAES256 HSUEncryptionIcon
128 N/A
256
No
Yes
