RFP:GeneralRadioFramePattern Chapter10
RFP:GeneralRadioFramePattern
WhensettingtheRPF,thefollowingconsiderationsshouldbeborneinmind:
• WhensynchronizingRADWIN2000CPlusunitsyoumustuseRFPE
• WhensynchronizingRADWIN5000withRADWIN2000orWi nLink1000unitsyoumust
useRFPE
• RFPinfluencescapacityandlatency.
• UsingtheLinkBudgetCalculator,youcanseetheeff ectoftheRFPontheEthernet
throughput.
linkConfigurationandHSS
TheHubSiteSynchronizationSettingsdialogboxappearsintheHBSSiteConfiguration
window.
Figure10‐10:HSSSettingswindow
IfyouclicktheEnabledbox,thecentraldisplay(withOperationalstateopened)willlooklike
this:
Figure10‐11:SettingtheMast erODUasHSMorHSC
ContinueTxmeansthattheHBSasaclienttocontinuetoworkifthereisnoHSMpulse.
