Radwin 2000 C PLUS User Manual

RADWIN2000CPlusUserManual Release3.5.70 13‐4
VLANConfigurationUsingtheRADWINManager Chapter13
EgressDirection
VLANConfigurationUsingtheRADWIN
Manager
ManagementTrafficandEthernetServiceSeparation
YoucandefineaVLANIDformanagementtrafficseparation.Youshouldconfigurethesystem
topreventconflictsasdetailedbelow.
Whenconfiguredforthedefa ultoperationalmode,a“Providerport”will handleingress
trafficasfollows:
• FiltersframesthatarenottaggedwiththeProviderVLANID
• RemovestheProviderdoubletag
Therefore,ifaportisconfiguredformanagementtrafficseparationbyVLANandas‘Provider
port’,thenthereceivedmanagementframesmustbedoubletaggedasfollows:
Table13‐2:Portsettings‐Egressdirection
Transparent
Theport‘doesnothing’withregardtoVLANs‐outboundframesareleft
untouched.
Untagall
PortconfiguredtountaguserVLADtagsforallframes.
Filter
Disclaimer
IfyouarenotaVLANexpert,pleasebeawarethatincorrectVLAN
configurationmaycausehavoconyournetwork.Thefacilitiesdescribed
belowareofferedasaservicetoenableyoutogetbestvaluefromyour
RADWIN2000CPluslinksandareprovided“asis”.Undernocircumstances
doesRADWINacceptresponsibilityfornetworksystemorfinancial
damagesarisingfromincorrectuseoftheseVLANfacilities.
