RADWIN2000CPlusUserManual Release3.5.70 4‐15
InstallingaLink Chapter4

Figure4‐17:Flatpanelantennamountingkitadapt er
ItismountedonapoleinexactlythesamemannerastheODUitselfusingtheadaptershown
inFigure 4‐17.Thelefthandviewinshowstheknurledsurfaceadjacenttothemountingkit
ear.Therighthandviewshowstherecessforthemountingkitholdingnut.
Figure4‐18:FlatPanelantenna‐rearwithmountingkitadapter
MountingExternalAntennasusingPoleClamps
ManyoftheantennasofthetypesshowninFigure 4‐8usethestandardmountingkit.Some
thirdpartyantennasusepoleclamps,similartothoseshownbelow:
