RADWIN2000CPlusUserManual Release3.5.70 19‐3
SpectrumViewMainWindow Chapter19
UsethetopleftpaneltosettheSpectrumViewconfigurationparametersandchoosean
analysistype‐EntirelinkorSpecificODU.
Thesettingsar e“sticky”forthelinkandwi ll bereused.Theanalysisrangeislimitedfrom
4900to6050MHzwithamaximumdifferenceof500MHz.Erroneousentries
willbeshown
witharedborderlikethis:
Thetimeoutisthemaximumanalysistimepersite.Usethebottombuttonbartostartorstop
ananalysis:

Sincealargelinkwillclutteruptherighthanddisplayare a,youmayselectivelyShow,
minimizeorremovealinkmember.Anotherwayoffreeingupmorespaceforanalysis
displaysistohidethelefthandpanelusingthecircledarrow:
