HP8648 emulation mode
1GP71_0E 136 Rohde & Schwarz
Status Command / Function / Remark / Limitation
[SOURce:]FM:STATe value
Set / Query the (activation) state of the modulation.
Value:
ON | OFF | 1 | 0
Default:
OFF
[SOURce:]FM:SOURce value
Select / Query the signal source of the modulation.
Value:
INTernal[1], EXTernal | EXTernal, INTernal[1] | INTernal2
Default:
INTernal
[SOURce:]FM:EXTernal:COUPling value
Select / Query the coupling type, when modulation source is set to external.
Value:
AC | DC
Default:
DC
[SOURce:]FM:INTernal[1]:FREQuency value
Set / Query the frequency of the signal source.
Value:
400 HZ | 1 KHZ
Default:
1 KHZ
[SOURce:]FM:INTernal2:FREQuency value
Set / Query the frequency of the signal source.
Value:
20 HZ … 10 KHZ
Default:
1 KHZ
[SOURce:]FM:INTernal2:FUNCtion:SHAPe value.
Select / Query the waveform of the signal source.
Value:
SINe | TRIangle | SQUare | SAW
Default:
SINe
Remark:
SAW and TRIangle are not supported.
Table 132: FM subsystem
