R&S SMA100A - Wideband Frequency Modulation

AF2040 emulation mode
1GP71_0E 23 Rohde & Schwarz
Status Command / Function / Remark / Limitation
{AM | AM1 | AM2}[:DEPTH] value
Set AM depth.
Value:
num [PCT]
Default:
0.0 PCT
Remark:
Modulation depth of AM1 and AM2 is coupled on SM*.
Especially internal deviation cannot exceed external deviation.
{AM | AM1 | AM2}:INC value
Set AM depth step.
Value:
num [PCT]
Default:
1.0 PCT
{AM | AM1 | AM2}:{INTF1 | INTF2 | INTF3 | INTF4 | INTF5 | INTF6 | EXT1DC |
EXT1AC | EXT1ALC | ETX2DC | EXT2AC | EXT2ALC}
Select modulation source.
Remark:
External path 1 is equal to external path 2
{AM | AM1 | AM2}:ON
Turn AM modulation on.
{AM | AM1 | AM2}:OFF
Turn AM modulation off.
{AM | AM1 | AM2}:UP
Set AM depth on step up.
{AM | AM1 | AM2}:DN
Set AM depth on step down.
{AM | AM1 | AM2}:RETN
Return to original setting.
{AM | AM1 | AM2}:XFER
Treat current setting to be the new original setting.
{AM | AM1 | AM2}?
Query informations on AM modulation settings.
Table 16: Amplitude Modulation
• Wideband Frequency Modulation
Status Command / Function / Remark / Limitation
WBFM[:DEVN] value
WBFM:ON
WBFM:OFF
