HP8360 emulation mode
1GP71_0E 78 Rohde & Schwarz
8 HP8360 emulation mode
General
In this language emulation mode, the emulation software in the SM* emulates
the SCPI-compatible language, implemented in Agilents’s signal generators of
type
o HP83620A / B
o HP83630A / B
The emulation software is supported on signal generators of type
o SMF100
The signal generator HP83620 / HP83630 also supports a HP8340
compatible Pre-SCPI-language. For more information on that language,
please refer to the HP8340 emulation.
The emulation software simulates the HP8360 data model in the execution unit
and transfers most of the HP8360 parameters into the SM* database.
SM*
database
SM*
remote control
interface
SM*
frontpanel
SM*
hardware
Figure 5: HP8360 emulation model
Those HP8360 functions and parameters, having no direct equivalent SM*
function and parameter, are not supported by this emulation so far.
GPIB functions
Commands
The following table shows the commands, supported by the HP8360.
