R&S SMA100A - Status Reporting

AF2040 emulation mode
1GP71_0E 36 Rohde & Schwarz
Status Command / Function / Remark / Limitation
OPER?
Query informations on total operation time.
Remark:
0.0 is returned in any case.
ELAPSED?
Query informations on operation time since last reset.
Remark:
0.0 is returned in any case.
ERROR?
Query informations on next error from error queue.
Remarks:
Returns the original error message from the SM*.
No conversion is done to AF2040 error codes.
DEVTRG value
Select device trigger function.
EXTTRG value
Select External trigger function.
KLOCK
Disable keyboard entry.
KUNLOCK
Enable keyboard entry.
Table 32: Miscellaneous
• Status Reporting
Status Command / Function / Remark / Limitation
CCR?
Query the coupling condition register.
Remark:
Implemented as dummy register.
CSE value
Write the coupling status enable register.
Value:
0 … 255
Default:
0
Remark:
Implemented as dummy register.
CSE?
Read the coupling status enable register.
Remark:
Implemented as dummy register.
