AF2040 emulation mode
1GP71_0E 15 Rohde & Schwarz
GPIB functions
The following table shows the GPIB functions, supported by the AF2040.
Status Command Function / Remark / Limitation
DCL Device clear.
GET Goup execute trigger.
GTL Goto local mode.
LLO Local lockout.
REN Goto remote mode.
SDC Selective device clear.
SPD Serial-Poll disable.
SPE Serial-Poll enable.
SRQ Request service.
Table 6: AF2040 GPIB functions
GPIB functions
Commands
The following table shows the commands, supported by the AF2040.
•
Common
Status Command / Function / Remark / Limitation
*CLS
Clear all status registers and error queue.
*ESE value
Set / Query the bits of the event status enable register.
*ESR?
Query the bits of the event status register.
*IDN?
Query the ID string.
Format: “IFR,2041,123456789,2.008”
*OPC
*OPC?
Wait / Query for the completion of the command.
*OPT?
Query the instrument options.
*PUD value
*RST
Reset the instrument to the factory default power up state.
