HP8657 emulation mode
1GP71_0E 149 Rohde & Schwarz
Instrument initialisation
The (factory) default setting of the HP8657 is applied when
o applying a DCL, SDC to the GPIB interface.
o transmitting the first command after activating this emulation mode.
The following table shows the (factory) default setting, applied by the SM*’s
emulation software.
Subsystem Default setting
ADDITIONAL -
FREQUENCY CW = 100.0 MZ
CW STEP = 10.0 MZ
AMPLITUDE LEVEL = -143.5 DBM
LEVEL STEP = 10.0 DB
OFFSET = 0.0 DB
OUTPUT = ON
MODULATION (AM) DEPTH = 0.0 PCT
DEPTH STEP = 1.0 PCT
STATE = OFF
SOURCE = INTERNAL
FREQUENCY = 1.0 KHZ
MODULATION (AM) DEVIATION = 0.0 KHZ
DEVIATION STEP = 10.0 KHZ
STATE = OFF
SOURCE = INTERNAL
FREQUENCY = 1.0 KHZ
MODULATION (PULSE) STATE = OFF
SOURCE = INTERNAL
FREQUENCY = 1.0 KHZ
Table 147: factory default setting
Additionally, all (backup) registers 0 … 99 are preset to the factory defaults,
too.
Status reporting
Status reporting is generally not supported by the HP8657.
