R&S SMA100A - Amplitude Modulation

AF2040 emulation mode
1GP71_0E 22 Rohde & Schwarz
Status Command / Function / Remark / Limitation
{PM | PM1 | PM2}[:DEVN] value
Set PM deviation.
Value:
num [RAD | RADS]
Default:
0.0 RAD
Remark:
Modulation deviation of PM1 and PM2 is coupled on SM*.
Especially internal deviation cannot exceed external deviation.
{PM | PM1 | PM2}:INC value
Set PM deviation step.
Value:
num [RAD | RADS]
Default:
0.1 RAD
{PM | PM1 | PM2}:{INTF1 | INTF2 | INTF3 | INTF4 | INTF5 | INTF6 | EXT1DC |
EXT1AC | EXT1ALC | ETX2DC | EXT2AC | EXT2ALC}
Select modulation source.
Remark:
External path 1 is equal to external path 2
{PM | PM1 | PM2}:ON
Turn PM modulation on.
{PM | PM1 | PM2}:OFF
Turn PM modulation off.
{PM | PM1 | PM2}:UP
Set PM deviation on step up.
{PM | PM1 | PM2}:DN
Set PM deviation on step down.
{PM | PM1 | PM2}:RETN
Return to original setting.
{PM | PM1 | PM2}:XFER
Treat current setting to be the new original setting.
{PM | PM1 | PM2}?
Query informations on PM modulation settings.
Table 15: Phase Modulation
• Amplitude Modulation
Status Command / Function / Remark / Limitation
