R&S SMA100A - Frequency; Amplitude; Modulation

HP8657 emulation mode
1GP71_0E 145 Rohde & Schwarz
o AM off
o AM depth 0 %
o FM off
o FM deviation 1 kHz
o PM off
o LF generator frequency 1 kHz
All registers 0 … 99 are also preset to the factory defaults.
Table 142: Additional commands
• Frequency
Status Command / Function / Remark / Limitation
CW value
Select fixed frequency function, optionally set fixed frequency.
Value:
value in HZ | KZ | MZ
Default:
100.0 MZ
Table 143: Frequency commands
• Amplitude
Status Command / Function / Remark / Limitation
AP value
Select amplitude function, optionally set amplitude.
Value:
value in DM | DF | DM VL | DM MV | DM UV | DM EM VL | DM EM UV | EM VL | EM
MV | EM UV | VL | MV | UV
Default:
-143.5 DM
Remark:
DF (dBf) is not supported.
AO value
Set amplitude offset.
Value:
value in DB
Default:
0.0 DB
Table 144: Amplitude commands
• Modulation
Status Command / Function / Remark / Limitation
AM value
Select amplitude modulation function, optionally set modulation depth.
