R&S SMA100A - Abort Subsystem; Control Subsystem; Diagnostic Subsystem

AN680XX emulation mode
1GP71_0E 43 Rohde & Schwarz
Status Command / Function / Remark / Limitation
*RCL value
Recall an instrument setup.
Value:
0 … 9
*RST
Reset the instrument to a default state.
*SAV value
Save an instrument setup.
Value:
0 … 9
*SRE value
Set / Query the bits of the status enable register.
*STB?
Query the bits of the status register.
*TRG
Trigger an action.
*TST?
Execute the instruments self test
*WAI
Wait until al commands are completed.
Table 36: Common commands
• ABORt Subsystem
Status Command / Function / Remark / Limitation
ABORt
Table 37: ABORT subsystem
• CONTrol Subsystem
Status Command / Function / Remark / Limitation
CONTrol:BLANking:POLarity value
CONTrol:PENLlift:POLarity value
CONTrol:RAMP[:STATe] value
CONTrol:RAMP:REST value
CONTrol:RAMP:TIME value
Table 38: CONTROL subsystem
• DIAGnostic Subsystem
Status Command / Function / Remark / Limitation
