AF2040 emulation mode
1GP71_0E 25 Rohde & Schwarz
Status Command / Function / Remark / Limitation
{INTF1 | INTF2 | INTF3 | INTF4 |INTF5 | INTF6}[:FREQ] value
Set modulation oszillator frequency.
Value:
num [Hz | KHZ | MHZ |GHZ]
Default:
INF1 = 300.0 HZ, SINE
INF2 = 400.0 HZ, SINE
INF3 = 500.0 HZ, SINE
INF4 = 1000.0 HZ, SINE
INF5 = 3000.0 HZ, SINE
INF6 = 6000.0 HZ, SINE
Remark:
Only 2 of 6 modulation oszillator frequencies can be used at one time, because on
SM* only 2 LF generators are available.
Usage of the LF generators 1 and 2 depend on selected modulation mode,
modulation source and modulation oscillator waveforms.
{INTF1 | INTF2 | INTF3 | INTF4 |INTF5 | INTF6}:FREQ:INC value
Set modulation oszillator frequency step.
Value:
num [Hz | KHZ | MHZ |GHZ]
Default:
1.0 KHZ
{INTF1 | INTF2 | INTF3 | INTF4 |INTF5 | INTF6}:SIN
Set modulation oszillator waveform to sine.
Remark:
Modulation oszillator waveform can only be selected for 1 of 2 modulations
oszillators used.
{INTF1 | INTF2 | INTF3 | INTF4 |INTF5 | INTF6}:TRI
Set modulation oszillator waveform to triangle.
Remark:
Modulation oszillator waveform can only be selected for 1 of 2 modulations
oszillators used.
{INTF1 | INTF2 | INTF3 | INTF4 |INTF5 | INTF6}:SQU
Set modulation oscillator waveform to square.
Remark:
Modulation oscillator waveform can only be selected for 1 of 2 modulations
oszillators used.
{INTF1 | INTF2 | INTF3 | INTF4 |INTF5 | INTF6}:UP
Set modulation oszillator frequency one step up.
{INTF1 | INTF2 | INTF3 | INTF4 |INTF5 | INTF6}:DN
Set modulation oszillator frequency one step down.
{INTF1 | INTF2 | INTF3 | INTF4 |INTF5 | INTF6}:RETN
Return to original setting.
