AN680XX emulation mode
1GP71_0E 55 Rohde & Schwarz
SOURCE (CORRECTION) -
SOURCE (FREQUENCY MODE = CW
CW = 0.5 * (Fmin + Fmax)
CW STEP = 100.0 MHZ
START = FMin
STOP = Fmax
CENTER = 0.5 * (Fmin + Fmax)
SPAN = Fmax – Fmin
MULTIPLIER = 1.0
SOURCE (LIST) -
SOURCE (MARKER) FREQUENCY(M1) = 2.0 GHz
FREQUENCY(M2) = 8.4 GHz
FREQUENCY(M3) = 2.0 GHz
FREQUENCY(M4) = 5.0 GHz
FREQUENCY(M5) = 8.4 GHz
FREQUENCY(M6 = 8.4 GHz)
FREQUENCY(M7) = 8.4 GHz
FREQUENCY(M8) = 8.4 GHz
FREQUENCY(M9) = 8.4 GHz
FREQUENCY(M10) = 3.5 GHz
STATE = OFF
POLARITY = POSITIVE
SOURCE (POWER) MODE = CW
LEVEL = 0.0 DBM
LEVEL STEP = 0.1 DB
ATTENUATION = AUTO
ATTENUATION AUTO = ON
ATTENUATION STEP = 10.0 DB
CENTER = 0.5 * (Pmin + Pmax)
DISPLAY OFFSET = 0.0 DB
START = Pmin
STOP = Pmax
SPAN = Pmax - Pmin
SOURCE (SWEEP) FREQUENCY STEP = (Fmax – Fmin) / 10000
POWER STEP = 0.02 DB
DIRECTION = UP
DWELL = Tmin
POINTS = Fspan / Fstep and Pspan / Pstep
SPACING = LINEAR(F), LOGARITHMIC(P)
TIME = ???
STATUS -
SYSTEM LANGUAGE = “SCPI”
