(4) [1] to [4] pages

Sets a range trace. This is only available when the free trace mode is disabled. Select either of the following four

modes: [Disabled], [Point to Point], [Range], and [Event].

• Disabled

Disables a range trace.

Figure 5.33 Range Trace Setting (Disabled)
