RL78/F13, F14 CHAPTER 16 SERIAL INTERFACE IICA

R01UH0368EJ0210 Rev.2.10 1078

Dec 10, 2015

(4) Operation without communication

(a) Start ~ Code ~ Data ~ Data ~ Stop

1: IICS0 = 00000001B

Remark : Generated only when SPIE0 = 1

(5) Arbitration loss operation (operation as slave after arbitration loss)

When the device is used as a master in a multi-master system, read the MSTS0 bit each time interrupt request signal

INTIICA0 has occurred to check the arbitration result.

(a) When arbitration loss occurs during transmission of slave address data

(i) When WTIM0 = 0

1: IICS0 = 0101×110B

2: IICS0 = 0001×000B

3: IICS0 = 0001×000B

4: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1

×: Don’t care

ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP

3 4 2
