RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)
R01UH0368EJ0210 Rev.2.10 1379
Dec 10, 2015
18.3.82 CAN RAM Test Register r (RPGACCr) (r = 0 to 127)
Address RPGACC0L: F0580H, RPGACC0H: F0581H RPGACC1L: F0582H, RPGACC1H: F0583H RPGACC2L: F0584H, RPGACC2H: F0585H
RPGACC3L: F0586H, RPGACC3H: F0587H RPGACC4L: F0588H, RPGACC4H: F0589H RPGACC5L: F058AH, RPGACC5H: F058BH
RPGACC6L: F058CH, RPGACC6H: F058DH RPGACC7L: F058EH, RPGACC7H: F058FH RPGACC8L: F0590H, RPGACC8H: F0591H
RPGACC9L: F0592H, RPGACC9H: F0593H RPGACC10L: F0594H, RPGACC10H: F0595H RPGACC11L: F0596H, RPGACC11H: F0597H
RPGACC12L: F0598H, RPGACC12H: F0599H RPGACC13L: F059AH, RPGACC13H: F059BH RPGACC14L: F059CH, RPGACC14H: F059DH
RPGACC15L: F059EH, RPGACC15H: F059FH RPGACC16L: F05A0H, RPGACC16H: F05A1H RPGACC17L: F05A2H, RPGACC17H: F05A3H
RPGACC18L: F05A4H, RPGACC18H: F05A5H RPGACC19L: F05A6H, RPGACC19H: F05A7H RPGACC20L: F05A8H, RPGACC20H: F05A9H
RPGACC21L: F05AAH, RPGACC21H: F05ABH RPGACC22L: F05ACH, RPGACC22H: F05ADH RPGACC23L: F05AEH, RPGACC23H: F05AFH
RPGACC24L: F05B0H, RPGACC24H: F05B1H RPGACC25L: F05B2H, RPGACC25H: F05B3H RPGACC26L: F05B4H, RPGACC26H: F05B5H
RPGACC27L: F05B6H, RPGACC27H: F05B7H RPGACC28L: F05B8H, RPGACC28H: F05B9H RPGACC29L: F05BAH, RPGACC29H: F05BBH
RPGACC30L: F05BCH, RPGACC30H: F05BDH RPGACC31L: F05BEH, RPGACC31H: F05BFH RPGACC32L: F05C0H, RPGACC32H: F05C1H
RPGACC33L: F05C2H, RPGACC33H: F05C3H RPGACC34L: F05C4H, RPGACC34H: F05C5H RPGACC35L: F05C6H, RPGACC35H: F05C7H
RPGACC36L: F05C8H, RPGACC36H: F05C9H RPGACC37L: F05CAH, RPGACC37H: F05CBH RPGACC38L: F05CCH, RPGACC38H: F05CDH
RPGACC39L: F05CEH, RPGACC39H: F05CFH RPGACC40L: F05D0H, RPGACC40H: F05D1H RPGACC41L: F05D2H, RPGACC41H: F05D3H
RPGACC42L: F05A4H, RPGACC42H: F05D5H RPGACC43L: F05D6H, RPGACC43H: F05D7H RPGACC44L: F05D8H, RPGACC44H: F05D9H
RPGACC45L: F05DAH, RPGACC45H: F05DBH RPGACC46L: F05DCH, RPGACC46H: F05DDH RPGACC47L: F05DEH, RPGACC47H: F05DFH
RPGACC48L: F05E0H, RPGACC48H: F05E1H RPGACC49L: F05E2H, RPGACC49H: F05E3H RPGACC50L: F05E4H, RPGACC50H: F05E5H
RPGACC51L: F05E6H, RPGACC51H: F05E7H RPGACC52L: F05E8H, RPGACC52H: F05E9H RPGACC53L: F05EAH, RPGACC53H: F05EBH
RPGACC54L: F05ECH, RPGACC54H: F05EDH RPGACC55L: F05EEH, RPGACC55H: F05EFH RPGACC56L: F05F0H, RPGACC56H: F05F1H
RPGACC57L: F05F2H, RPGACC57H: F05F3H RPGACC58L: F05F4H, RPGACC58H: F05F5H RPGACC59L: F05F6H, RPGACC59H: F05F7H
RPGACC60L: F05F8H, RPGACC60H: F05F9H RPGACC61L: F05FAH, RPGACC61H: F05FBH RPGACC62L: F05FCH, RPGACC62H: F05FDH
RPGACC63L: F05FEH, RPGACC63H: F05FFH RPGACC64L: F0600H, RPGACC64H: F0601H RPGACC65L: F0602H, RPGACC65H: F0603H
RPGACC66L: F0604H, RPGACC66H: F0605H RPGACC67L: F0606H, RPGACC67H: F0607H RPGACC68L: F0608H, RPGACC68H: F0609H
RPGACC69L: F060AH, RPGACC69H: F060BH RPGACC70L: F060CH, RPGACC70H: F060DH RPGACC71L: F060EH, RPGACC71H: F060FH
RPGACC72L: F0610H, RPGACC72H: F0611H RPGACC73L: F0612H, RPGACC73H: F0613H RPGACC74L: F0614H, RPGACC74H: F0615H
RPGACC75L: F0616H, RPGACC75H: F0617H RPGACC76L: F0618H, RPGACC76H: F0619H RPGACC77L: F061AH, RPGACC77H: F061BH
RPGACC78L: F061CH, RPGACC78H: F061DH RPGACC79L: F061EH, RPGACC79H: F061FH RPGACC80L: F0620H, RPGACC80H: F0621H
RPGACC81L: F0622H, RPGACC81H: F0623H RPGACC82L: F0624H, RPGACC82H: F0625H RPGACC83L: F0626H, RPGACC83H: F0627H
RPGACC84L: F0628H, RPGACC84H: F0629H RPGACC85L: F062AH, RPGACC85H: F062BH RPGACC86L: F062CH, RPGACC86H: F062DH
RPGACC87L: F062EH, RPGACC87H: F062FH RPGACC88L: F0630H, RPGACC88H: F0631H RPGACC89L: F0632H, RPGACC89H: F0633H
RPGACC90L: F0634H, RPGACC90H: F0635H RPGACC91L: F0636H, RPGACC91H: F0637H RPGACC92L: F0638H, RPGACC92H: F0639H
RPGACC93L: F063AH, RPGACC93H: F063BH RPGACC94L: F063CH, RPGACC94H: F063DH RPGACC95L: F063EH, RPGACC95H: F063FH
RPGACC96L: F0640H, RPGACC96H: F0641H RPGACC97L: F0642H, RPGACC97H: F0643H RPGACC98L: F0644H, RPGACC98H: F0645H
RPGACC99L: F0646H, RPGACC99H: F0647H RPGACC100L: F0648H, RPGACC100H: F0649H RPGACC101L: F064AH, RPGACC101H: F064BH
RPGACC102L: F064CH, RPGACC102H: F064DH RPGACC103L: F064EH, RPGACC103H: F064FH RPGACC104L: F0650H, RPGACC104H: F0651H
RPGACC105L: F0652H, RPGACC105H: F0653H RPGACC106L: F0654H, RPGACC106H: F0655H RPGACC107L: F0656H, RPGACC107H: F0657H
RPGACC108L: F0658H, RPGACC108H: F0659H RPGACC109L: F065AH, RPGACC109H: F065BH RPGACC110L: F065CH, RPGACC110H: F065DH
RPGACC111L: F065EH, RPGACC111H: F065FH RPGACC112L: F0660H, RPGACC112H: F0661H RPGACC113L: F0662H, RPGACC113H: F0663H
RPGACC114L: F0664H, RPGACC114H: F0665H RPGACC115L: F0666H, RPGACC115H: F0667H RPGACC116L: F0668H, RPGACC116H: F0669H
RPGACC117L: F066AH, RPGACC117H: F066BH RPGACC118L: F066CH, RPGACC118H: F066DH RPGACC119L: F066EH, RPGACC119H: F066FH
RPGACC120L: F0670H, RPGACC120H: F0671H RPGACC121L: F0672H, RPGACC121H: F0673H RPGACC122L: F0674H, RPGACC122H: F0675H
RPGACC123L: F0676H, RPGACC123H: F0677H RPGACC124L: F0678H, RPGACC124H: F0679H RPGACC125L: F067AH, RPGACC125H: F067BH
RPGACC126L: F067CH, RPGACC126H: F067DH RPGACC127L: F067EH, RPGACC127H: F067FH
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
RDTA[15:0]
After Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Description R/W
Data can be read and written in CAN RAM. R/W
Modify the RPGACCr register in global test mode with the RTME bit in the GTSTCTRL register set to 1 (RAM test is
enabled). The RPGACCr register is readable and writable when the RTME bit is set to 1.
This register can be read/written when the RPAGE bit in the GRWCR register is 0.
