RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 323
Dec 10, 2015
4.3.4 Port input mode registers (PIM1, PIM3, PIM5 to PIM7, PIM12)
These registers set the input buffer of P10, P11, P13, P14, P16, P17, P30, P54, P62, P63, P70, P71, P73, and P125
in 1-bit units.
TTL input buffer can be selected during serial communication with an external device of the different potential.
These registers can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears these registers to 00H.
Figure 4-77. Format of Port Input Mode Register (100-pin products)
Symbol 7 6 5 4 3 2 1 0 Address After reset R/W
PIM1
PIM17 PIM16 0 PIM14 PIM13 0 PIM11 PIM10 F0041H
00H R/W
PIM3
0 0 0 0 0 0 0 PIM30 F0043H
00H R/W
PIM5 0 0 0 PIM54 0 0 0 0 F0045H
00H R/W
PIM6 0 0 0 0 PIM63 PIM62 0 0 F0046H
00H R/W
PIM7 0 0 0 0 PIM73 0 PIM71 PIM70 F0047H
00H R/W
PIM12 0 0 PIM125 0 0 0 0 0 F004CH
00H R/W
PIMmn
Pmn pin input buffer selection
(m = 1, 3, 5 to 7, 12; n = 0 to 7)
0 Normal input buffer
1 TTL input buffer
Caution Be sure to set bits for pins that are not present to their initial values.
