RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1109
Dec 10, 2015
17.2.1 LIN Registers for Master Mode
(1) Input Switch Control Register (ISC)
The ISC2 and ISC3 bits in the ISC register are used in the LIN/UART module (RLIN3).
Setting bit 2 or bit 3 to 1 selects the input signal of the serial data input pin for the LIN/UART module as the external interrupt
input.
This register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation sets this register to 00H.
ddress: F0073H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
ISC 0 0 0 0 ISC3 ISC2 0 ISC0
ISC3 Switching inputs for external interrupt INTP12
0 INTP12 pin input signal is set as external interrupt input.
1 LRXD1 pin input signal is set as external interrupt input.
ISC2 Switching inputs for external interrupt INTP11
0 INTP11 pin input signal is set as external interrupt input.
1 LRXD0 pin input signal is set as external interrupt input.
ISC0 Switching inputs for external interrupt INTP0
0 INTP0 pin input signal is set as external interrupt input. (normal operation)
1 RXD0 pin input signal is set as external interrupt input. (wake-up signal detection)
Caution Bits 7 to 4 and 1 should always be set to 0.
