RL78/F13, F14 CHAPTER 19 DTC

R01UH0368EJ0210 Rev.2.10 1447

Dec 10, 2015

19.2.16 High-speed DTC Transfer Count Register m (HDTCCT0/1) (m = 0, 1)

This register is used to set the number of high-speed DTC data transfers. The value is decremented by 1 each time DTC

transfer is activated once.

Figure 19-16. Format of High-speed DTC Transfer Count Register m (HDTCCTm)

Address: F02D2H (HDTCCT0), F02DAH (HDTCCT1) After reset: 00H

Symbol 7 6 5 4 3 2 1 0

HDTCCTm HDTCCTm7 HDTCCTm6 HDTCCTm5 HDTCCTm4 HDTCCTm3 HDTCCTm2 HDTCCTm1 HDTCCTm0

HDTCCTm Number of Transfers R/W

00H 256 times R/W

01H Once

02H 2 times

03H 3 times

FDH 253 times

FEH 254 times

FFH 255 times

Caution Do not access the HDTCCTm register using a high-speed DTC transfer.
