RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 331
Dec 10, 2015
4.3.10 Peripheral I/O redirection register 1 (PIOR1)
This register is used to specify whether to enable or disable the peripheral I/O redirect function.
PIOR1 enables or disables redirection of the timer array unit functions; that is, it specifies which I/O port is assigned to
each output pin of timer array unit 0.
This register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 4-83. Format of Peripheral I/O Redirection Register 1 (PIOR1)
Address: F0017H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
PIOR1 PIOR17 PIOR16 PIOR15 PIOR14 PIOR13 PIOR12 PIOR11 PIOR10
Bit Function 100-pin 80-pin 64-pin 48-pin
Setting value Setting value Setting value Setting value
0 1 0 1 0 1 0 1
PIOR17 TO07
P120 P44 P120 P44 P120

P120

PIOR16 TO06
P14 P02 P14 P02 P14

P14

PIOR15 TO05
P15 P00 P15 P00 P15 P00 P15 P00
PIOR14 TO04
P13 P01 P13 P01 P13

P13

PIOR13 TO03
P125 P127 P125

P125

P125

PIOR12 TO02
P16 P67 P16 P67 P16

P16

PIOR11 TO01
P30 P126 P30 P126 P30

P30

PIOR10 TO00
P17 P66 P17 P66 P17

P17

Caution The 32-, 30-, and 20-pin products do not have the PIOR1 register.
