RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT
R01UH0368EJ0210 Rev.2.10 805
Dec 10, 2015
15.3.3 Serial mode register mn (SMRmn)
The SMRmn register is a register that sets an operation mode of channel n. It is also used to select an operation
clock (fMCK), specify whether the serial clock (fSCK) may be input or not, set a start trigger, an operation mode (CSI,
UART, or simplified I
2
C), and an interrupt source. This register is also used to invert the level of the receive data only
in the UART mode.
Rewriting the SMRmn register is prohibited when the register is in operation (when SEmn = 1). However, the MDmn0
bit can be rewritten during operation.
Set the SMRmn register by a 16-bit memory manipulation instruction.
Reset signal generation sets the SMRmn register to 0020H.
Figure 15-6. Format of Serial Mode Register mn (SMRmn) (1/2)
Address: F0108H, F0109H (SMR00), F010AH, F010BH (SMR01), After reset: 0020H R/W
F0148H, F0149H (SMR10), F014AH, F014BH (SMR11)
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SMRmn
CKS
mn
CCS
mn
0 0 0 0 0
STS
mn
0
SIS
mn0
1 0 0
MD
mn2
MD
mn1
MD
mn0
CKS
mn
Selection of operation clock (f
MCK) of channel n
0 Operation clock CKm0 set by the SPSm register
1 Operation clock CKm1 set by the SPSm register
Operation clock (fMCK) is used by the edge detector. In addition, depending on the setting of the CCSmn bit and the
higher 7 bits of the SDRmn register, a transfer clock (f
TCLK) is generated.
CCS
mn
Selection of transfer clock (f
TCLK) of channel n
0 Divided operation clock fMCK specified by the CKSmn bit
1 Clock input fSCK from the SCKp pin (slave transfer in CSI mode)
Transfer clock fTCLK is used for the shift register, communication controller, output controller, interrupt controller, and
error controller. When CCSmn = 0, the division ratio of operation clock (f
MCK) is set by the higher 7 bits of the
SDRmn register.
STS
mn
Selection of start trigger source
0 Only software trigger is valid (selected for CSI, UART transmission, and simplified I
2
C).
1 Valid edge of the RXDq pin (selected for UART reception)
Transfer is started when the above source is satisfied after 1 is set to the SSm register.
Caution Be sure to clear bits 13 to 9, 7, 4, and 3 to 0. Be sure to set bit 5 to 1.
Remark m: Unit number (m = 0, 1), n: Channel number (n = 0, 1), p: CSI number (p = 00, 01, 10, 11),
q: UART number (q = 0, 1), r: IIC number (r = 00, 01, 10, 11)
To Next Page
