4.3.17 Peripheral I/O redirection register 8 (PIOR8)
This register is used to specify whether to enable or disable the peripheral I/O redirect function.
PIOR8 enables or disables redirection of the real-time clock correction clock (1 Hz) output function; that is, it specifies
which I/O port is assigned to the real-time clock correction clock (1 Hz) output pin.
This register can be set by an 8-bit memory manipulation instruction.
Bits 7 to 1 are read-only. Bit 0 can be read or written to.
After reset cancellation, this register can always be read or written to.
Any reset source clears this register to 00H.
Figure 4-90. Format of Peripheral I/O Redirection Register 8 (PIOR8)
Address: F001EH After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
PIOR8 0 0 0 0 0 0 0 PIOR80
Bit Function 100-pin
Setting value
0 1
PIOR87
  
PIOR86
  
PIOR85
  
PIOR84
  
PIOR83
  
PIOR82
  
PIOR81
  
PIOR80 RTC1HZ P15 P03
Caution The 80-, 64-, 48-, 32-, 30-, and 20-pin products do not have the PIOR8 register.
