RL78/F13, F14
CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ021
0 Rev.2.10
145
Dec 10, 2015
3.2.3 ES and CS registers
The ES register is used for data access and the CS register is used to s
pecify the higher address
when a branch
instruction is executed.
The default value of the ES register after reset is
0FH, and that of the
CS register is 00H.
Figure 3-41. Configura
