RL78/F13, F14 CHAPTER 14 COMPARATOR (RL78/F14 Only)
R01UH0368EJ0210 Rev.2.10 784
Dec 10, 2015
14.2.6 D/A converter mode register 2 (DAM2)
When the P80/ANO0 pin is in use to output analog signal from the D/A converter, this register is used to control the output
from the ANO0 pin. When setting bits 5 and 4 (CVRS1 and CVRS0) in the comparator I/O select register (CMPSEL) to 10B
(internal reference voltage (DAC output) is selected), set the ANO0EN bit in this register to 0 (analog output is disabled).
The DAM2 register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation sets this register to 00H.
Figure 14-7. Format of D/A Converter Mode Register (DAM2)
Address: F0227H After reset: 00H
Symbol 7 6 5 4 3 2 1 <0>
DAM2 0 0 0 0 0 0 0 ANO0EN
ANO0EN Analog output (ANO0) control R/W
0 Analog output (ANO0) is disabled. R/W
1 Analog output (ANO0) is enabled.
To Next Page
