RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT
R01UH0368EJ0210 Rev.2.10 804
Dec 10, 2015
15.3.2 Serial clock select register m (SPSm)
The SPSm register is a 16-bit register that is used to select two types of operation clocks (CKm0, CKm1) that are
commonly supplied to each channel. CKm1 is selected by bits 7 to 4 of the SPSm register, and CKm0 is selected
by bits 3 to 0.
Rewriting the SPSm register is prohibited when the register is in operation (when SEmn = 1).
The SPSm register can be set by a 16-bit memory manipulation instruction.
Set the lower 8 bits of the SPSm register with an 8-bit memory manipulation instruction with SPSmL.
Reset signal generation clears the SPSm register to 0000H.
Figure 15-5. Format of Serial Clock Select Register m (SPSm)
A
ddress: F0116H, F0117H (SPS0), F0156H, F0157H (SPS1) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SPSm 0 0 0 0 0 0 0 0
PRS
m13
PRS
m12
PRS
m11
PRS
m10
PRS
m03
PRS
m02
PRS
m01
PRS
m00
PRS
mk3
PRS
mk2
PRS
mk1
PRS
mk0
Section of operation clock (CKmk)
Note
fCLK = 2 MHz fCLK = 5 MHz fCLK = 10 MHz fCLK = 20 MHz fCLK = 32 MHz
0 0 0 0 fCLK 2 MHz 5 MHz 10 MHz 20 MHz 32 MHz
0 0 0 1 fCLK/2 1 MHz 2.5 MHz 5 MHz 10 MHz 16 MHz
0 0 1 0 fCLK/2
2
500 kHz 1.25 MHz 2.5 MHz 5 MHz 8 MHz
0 0 1 1 fCLK/2
3
250 kHz 625 kHz 1.25 MHz 2.5 MHz 4 MHz
0 1 0 0 fCLK/2
4
125 kHz 313 kHz 625 kHz 1.25 MHz 2 MHz
0 1 0 1 fCLK/2
5
62.5 kHz 156 kHz 313 kHz 625 kHz 1 MHz
0 1 1 0 fCLK/2
6
31.3 kHz 78.1 kHz 156 kHz 313 kHz 500 kHz
0 1 1 1 fCLK/2
7
15.6 kHz 39.1 kHz 78.1 kHz 156 kHz 250 kHz
1 0 0 0 fCLK/2
8
7.81 kHz 19.5 kHz 39.1 kHz 78.1 kHz 125 kHz
1 0 0 1 fCLK/2
9
3.91 kHz 9.77 kHz 19.5 kHz 39.1 kHz 62.5 kHz
1 0 1 0 fCLK/2
10
1.95 kHz 4.88 kHz 9.77 kHz 19.5 kHz 31.3 kHz
1 0 1 1 fCLK/2
11
977 Hz 2.44 kHz 4.88 kHz 9.77 kHz 15.6 kHz
Other than above Setting prohibited
Note When changing the clock selected for fCLK (by changing the system clock control register (CKC) value), do
so after having stopped (serial channel stop register m (STm) = 0003H) the operation of the serial array units
(SAUs).
Caution Be sure to clear bits 15 to 8 to 0.
Remarks 1. f
CLK: CPU/peripheral hardware clock frequency
fSUB: Subsystem clock frequency
2. m: Unit number (m = 0, 1), k = 0, 1
